ICON 14-18 GM 1500 1-3in Stage 5 Suspension System (Large Taper)

Manufacturer Part # : K73005A

Market Description

• ICON Vehicle Dynamics 2014-2018 GM Silverado/Sierra 1500 suspension systems are designed to dramatically increase the on and off-road ride quality. ICON engineers’ primary focus is to increase wheel travel and damping ability, which translates into outstanding vehicle control and ride quality both on and off-road. With wheel travel and ride quality in mind, ICON engineers researched each component of the GM platform’s suspension and addressed any areas where performance could be extracted. The Stage 5 system provides a higher level of performance that will drastically improve overall on and off-road vehicle ride characteristics. ICON's Vehicle-specific tuned 2.5” remote reservoir coilover shocks and ICON 2.5 Aluminum Series piggyback rear shocks w/ CDCV in this system provide exceptional cooling properties, with the coilovers utilizing ICON-engineered Eibach coil springs for superior vehicle “feel” throughout the range of travel. Remote reservoirs front and rear ensure optimum performance by increasing the duration of consistent damping, keeping the shocks at a cooler operating temperature during extended off-road use. These 2.5" remote reservoir coilovers w/ CDCV are also height adjustable from 1-2.5” of lift allowing the use of larger, more aggressive wheel and tire combinations when desired. The ICON Vehicle Dynamics 2014-2018 GM Silverado/Sierra 1500 Stage 5 suspension system is an excellent choice for those drivers looking to enhance the capabilities of their pickup on the road as well as optimum performance in the dirt.
• This system features upper control arms with ICON's patented Delta Joint. The Delta Joint is a heavy-duty high angle ball joint that combines the durability of a ball joint with the performance characteristics of a traditional uniball. While the industry standard uniball does a great job of allowing the control arms of a vehicle to articulate with little bind, they do have an inherent weakness that leaves more to be desired when used in a daily driven application - exposure to the elements. The Delta Joint features a zinc plated housing providing the first layer of corrosion resistance, while a tough grease seal keeps potentially harmful elements out of the inner workings of the joint. Metal on metal construction and a greaseable design increase the longevity of the Delta Joint while at the same time allowing for noise-free operation. What makes the Delta Joint unique is that it brings the best of both worlds to ICON upper control arms with features that make it more robust than a uniball, and at the same time capable of greater angularity than a typical ball joint.

Associated Comments

• Recommended Aftermarket Tires: 33" x 11.50" (Larger tires may fit but fender trimming and modifications will be required.)
• TECH NOTE: Large taper applications can be identified by the stamped steel or aluminum OE front lower control arms
• APPLICATION NOTE #55: SHOCKS ARE FULLY SERVICEABLE. COILOVER HEIGHTS INDICATED ARE FOR A STOCK EQUIPPED VEHICLE
• TECH NOTE: Only compatible with OE spindles. DO NOT install in combination with ANY aftermarket spindles.
• TECH NOTE: Also compatible with 2019 Chevrolet Silverado 1500 LD and 2019 GMC Sierra 1500 Limited
• Recommended Aftermarket Wheels: ICON Alloys - 17x8.5" w/ 4.75” Backspace / 0mm Offset
• Recommended Aftermarket Wheels: ICON Alloys - 18x9" w/ 5.00” Backspace / 0mm Offset
• Recommended Aftermarket Wheels: ICON Alloys - 20x9" w/ 5.00” Backspace / 0mm Offset
• APPLICATION NOTE #48: SLIGHT MODIFICATIONS TO FACTORY SHOCK MOUNTS MAY BE REQUIRED
• TECH NOTE: Not compatible with models equipped Magnetic Ride Control
• APPLICATION NOTE #89: DOES NOT WORK ON SUV MODELS
• TECH NOTE: Not compatible with Hybrid models

Features and Benefits

• Increased wheel travel and ride quality over stock with no change in towing capacity
• Vehicle specific tuned front and rear shocks for superior shock damping and control
• 100% Bolt-on system - no drilling, cutting, or welding necessary for install
• 2.5 Aluminum Series piggyback reservoir rear shocks with 7/8" shock shafts
• ICON CDCV equipped shocks for fully adjustable tuneability of your shocks
• Corrosion resistant CAD plated coilover shock body with 7/8 shaft
• FK rod end bearings for extended longevity and minimal deflection
• Adjustable remote reservior coilovers from 1-3" of lift height
• 6061 Aircraft grade aluminum CNC machined components
• High strength alloy CNC machined lower bar pin
• Fits 2WD and 4WD models

Product Description - Extended

2014-2018 GM 1500 1-2.5" LIFT STAGE 5 SUSPENSION SYSTEM (LARGE TAPER)

Product Description - Short

• ICON 14-18 GM 1500 1-3in Stage 5 Suspension System (Large Taper)
• SUSPENSION SYSTEM

Product Description - Long

14-18 GM 1500 1-2.5" STAGE 5 SUSPENSION SYSTEM (LARGE TAPER)

Product Description - Invoice

14-18 GM 1500 STG 5 SUSP SYS LARGE TAPER

AAIA Part Type Description

Suspension Lift Kit
