ICON 2011+ GM 2500HD/3500 0-2in Stage 2 Suspension System

Manufacturer Part # : K78102

Market Description

• This system features upper control arms with ICON's patented Delta Joint. The Delta Joint is a heavy-duty high angle ball joint that combines the durability of a ball joint with the performance characteristics of a traditional uniball. While the industry standard uniball does a great job of allowing the control arms of a vehicle to articulate with little bind, they do have an inherent weakness that leaves more to be desired when used in a daily driven application - exposure to the elements. The Delta Joint features a zinc plated housing providing the first layer of corrosion resistance, while a tough grease seal keeps potentially harmful elements out of the inner workings of the joint. Metal on metal construction and a greaseable design increase the longevity of the Delta Joint while at the same time allowing for noise-free operation. What makes the Delta Joint unique is that it brings the best of both worlds to ICON upper control arms with features that make it more robust than a uniball, and at the same time capable of greater angularity than a typical ball joint.
• The 2011-2019 GM 2500HD/3500HD requires significant shock damping to comply with the massive spring rate of the factory torsion bar system. ICON Vehicle Dynamics has developed a range of suspension systems with optimized vehicle specific shock damping. While driving the construction site or trails to your favorite dirt bike location, ICON wants you to get there in comfort just like your drive to work. ICON's Stage 2 system is comprised of V.S. 2.5 Aluminum Series piggyback front & rear shocks, and tubular Delta Joint upper control arms. The ICON vehicle specific tuned 2.5" shocks are the key to attaining optimum ride quality and getting that desired comfort with the 3/4 & 1-ton working capability. Reservoir shocks ensure optimum performance by increasing the duration of consistent damping regardless of situation, keeping the shocks at a cooler operating temperature during heavy use. Additionally, ICON upper control arms add strength, durability, and when paired with extended travel shocks increases wheel travel 2" over the OEM configuration.

Associated Comments

• APPLICATION NOTE #113: 26.13" IS MAX MEASUREMENT FROM FENDER TO HUB, EXCEEDING THE MAXIMUM LIFT HEIGHT OF 26.13" CAN LEAD TO COMPONENT FAILURE NOT COVERED BY ICON WARRANTY
• Recommended Aftermarket Tires: 33" x 11.50" (Larger tires may fit but fender trimming and modifications will be required.)
• APPLICATION NOTE #55: SHOCKS ARE FULLY SERVICEABLE. COILOVER HEIGHTS INDICATED ARE FOR A STOCK EQUIPPED VEHICLE
• Recommended Aftermarket Wheels: ICON Alloys - 18x9" w/ 5.50" Backspace / 12mm Offset
• Recommended Aftermarket Wheels: ICON Alloys - 20x9" w/ 5.50" Backspace / 12mm Offset
• APPLICATION NOTE #65: NOT SOLD SEPARATELY, ONLY SOLD IN COMPLETE KIT FORM AS LISTED
• OEM Wheels & Tires Fitment: Yes
• Ships in multiple boxes

Features and Benefits

• 2.5 Aluminum Series front and rear shocks feature one-piece impact extruded aluminum cylinders for excellent corrosion resistance and consistent finish
• Vehicle specific tuned 2.5" front and rear shocks for superior shock damping and control
• 100% Bolt-on system - no drilling, cutting, or welding necessary for install
• Improved ride quality over stock with no change in towing capacity
• 6061 Aircraft grade aluminum CNC machined components
• Wheel travel increase of 2" over stock

Product Description - Extended

2011-2019 GM 2500HD/3500 0-2" LIFT STAGE 2 SUSPENSION SYSTEM

Product Description - Short

• ICON 2011+ GM 2500HD/3500 0-2in Stage 2 Suspension System
• SUSPENSION SYSTEM

Product Description - Long

11-19 GM 2500HD/3500 0-2" STAGE 2 SUSPENSION SYSTEM

Product Description - Invoice

11-19 GM HD 0-2" STAGE 2 SUSP SYSTEM

AAIA Part Type Description

Suspension Lift Kit
